Gallagher Security -- access control and perimeter security for high-security sites.

35+Years designing security
140+Countries trusted in
20,000+Security customers worldwide
15%Of revenue invested in R&D
C7000ControllerRuns on if server dropsMobileCommand CentreAlarms on your phoneCard · grantedFence touchedArea armedDoors, alarms, fenceAES-256 encrypted
10,000Controller 7000s in a single system, scaling up from one door
200 msresponse at a T-Series reader, whether card or phone
Class 5AS/NZS 2201 certification for Gallagher intruder alarms
Zone 1–5Australian security zones the high-security system is endorsed for
Two ways to run it

Command Centre on a server, or Gallagher SMB in the cloud

Larger and more complex sites run doors, alarms and perimeter from Command Centre on their own server. Shops, clinics, clubs and branch networks are often better served by Gallagher SMB, which needs no server at all. We help you choose on size, risk and how the site is managed.

Main gateLab 2StoreFence Z4Dock camCar parkGuardDoors, alarms and fence on one site plan
Server-based

Command Centre

Gallagher’s site management software runs access control, intruder alarms and perimeter fencing as one system on your own server, with Command Centre Web and Mobile for running it away from the desk. It grows from one door to thousands, with new releases twice a year.

  • Site plans, alarms, reports and notifications built in
  • Anti-passback, interlocking, zone counting and guard tours
  • Licensed add-ons for video, lifts, intercoms, car parks and lockers
  • AccessNow handles access requests from asking to approval
Gallagher SMBAlarm · rearFlorist · back doorToday 11:52 pmRequest guardLock all doorsArmFrom the appDoorsApp or Key TagMonitoring24/7 response
Cloud, app-based

Gallagher SMB

A cloud system for smaller sites, with no server to install or look after. Alarms, doors and users are run from one phone app across as many locations as the business has, and the software updates itself.

  • Arm and disarm remotely from the SMB app
  • Doors by phone or SMB Key Tag, with access schedules
  • Add or remove staff and contractors in moments
  • Ask a connected security provider for a guard check
What it does

Doors, alarms and fences on one platform

Gallagher designs and builds its own controllers, readers, fence hardware and software, so the pieces are made to work together. These are the parts we set up most often.

To serverController 7000Runs on if server dropsDoorsReadersAlarmsFenceLiftsBMSUp to 10 wired doors per controller, 256-bit AES back to the server

Controller 7000

The C7000 makes access, alarm and perimeter decisions itself, so business rules keep running if the link to the server drops. Each one handles up to 10 wired doors and talks to the server and other controllers over 256-bit AES. Single-door, two-door, standard, enhanced and high-security versions suit each part of a site.

CardPhoneWalletPINDoor open08:41 Phone · BLE08:39 Card · T1108:30 Card + PIN07:55 Wallet badge

Readers and mobile access

T-Series readers answer in about 200 milliseconds and take MIFARE cards, Bluetooth phones through Mobile Connect, and employee badges in Apple Wallet. The T20 adds a keypad for card plus PIN, and the range is rated up to IP68 and IK09 for exposed spots.

Pulse fence Z4Climb · wire tensionWind gust · ignored

Monitored pulse fencing

An energised fence that deters, plus sensors that read wire tension and vibration and tell an intruder from wildlife or weather. Voltage and alerts are set zone by zone, the pulses meet AS/NZS 60335.2.76, and fence events land in Command Centre beside the doors and alarms.

ArmedPlant room alarmReceptionArmedPlant roomPIR · 02:14Server roomArmedLoading dockRoller shutFence Z4Pulse onKitchenCleaners in

Intruder alarms

Intruder detection runs on the same controllers and software as the doors and the fence, so every event sits in one view with one audit trail. It is certified to AS/NZS 2201 Class 5 and passes alarms to external monitoring stations over standard protocols.

AccessNow · new requestI need access to Lab 2 for the next two weeksRequestedLab 2Until 14 NovApproverLab managerEmailed instantlyProvisionedCommand CentreOn approval

AccessNow

Staff ask for a card, a mobile credential, a secure area or a visitor pass from their phone. The request goes straight to the right approver, and once approved the access is set up in Command Centre automatically, with every decision logged.

Visitors · Head officeOn site now37Expected12Contractors6Inductions due2Arrivals by hourFront deskQR check-in · 09:12Host notified · 09:12Pass revoked · 10:45Induction overdue

Visitor management

A cloud visitor system, powered by Kenai, handles pre-registration, QR or face check-in, host alerts and induction records. Through Command Centre it issues the right credential for the visit, takes it back when the visitor leaves, and can run an evacuation roll call.

The range

What Gallagher makes

Software

  • Command Centre, Web and Mobile
  • Gallagher SMB
  • AccessNow
  • Visitor management, powered by Kenai
  • OneLink for remote assets

Access control hardware

  • Controller 7000 single door, two door, standard and enhanced
  • T-Series readers and terminals, T10 to T30
  • QuickSwitch boards for replacing older systems
  • Cards, tags and Mobile Connect credentials
  • Cabinets and power supplies

Perimeter

  • F-Series fence controllers
  • Pulse fence and gate hardware
  • Perimeter sensors
  • Starter kits

High security

  • High Security Controller 7000
  • High-security readers
  • High-security cabinets and end-of-line modules
  • PIV software
How it fits together

A Teracom Gallagher system, end to end

ON SITEPLATFORMPEOPLET-Series readersCard, phone, PINController 7000Doors and alarmsPulse fenceTension sensorsDetectorsIntruder zonesCommand CentreServer on siteGallagher SMBCloud, for small sitesSecurity deskSite plans, alarmsPhonesCC Mobile, SMB appTeracom monitoringAfter-hours alarmsControllers decide at the door; Command Centre ties access, alarms and the fence into one view

Gallagher readers, controllers, fencing and detectors report to Command Centre on site, or to Gallagher SMB in the cloud for smaller sites. Your team works from the security desk or a phone, and alarms can come through to our monitoring centre after hours.

Where we put it to work

  • Schools and universities
  • Healthcare
  • Government
  • Data centres
  • Utilities and critical infrastructure
  • Mining
  • Airports
  • Small businesses and clubs
Teracom and Gallagher

What Teracom does on a Gallagher job

  1. Design

    Doors, readers, alarm areas and fence zones planned from the site drawings, with controllers, cabling and power sized for the site to grow.

  2. Install and commission

    Controllers, readers and detectors installed and tested, with cardholders, access groups and alarm areas set up in Command Centre or the SMB app.

  3. Connect to monitoring

    Intruder and fence alarms can come through to our monitoring centre for after-hours response.

  4. Look after it

    Software releases, firmware and health checks handled on a maintenance plan, so the system stays current and supported.

From Gallagher: Gallagher Command Centre · Gallagher Controller 7000 · Gallagher CarePlan and warranty

Why Teracom works with Gallagher

Security built for high-stakes sites, at any scale.

Command Centre, One Platform

Command Centre unifies access control, intruder alarms and perimeter security in a single system that scales from one door to thousands.

Designed and Built In-House

Gallagher designs and manufactures its own hardware and software at its global headquarters, giving Teracom clients a vertically integrated stack instead of stitched-together third-party parts.

Cyber-Hardened by Default

The C7000 controller is built for modern cyber defense, backed by ISO 27001:2022 and SOC 2 Type II accreditation across Gallagher's security practices.

Trusted for High-Security Sites

Gallagher is an approved supplier to Five Eyes governments and is deployed across defense, critical infrastructure, mining and healthcare sites where failure is not an option.

Continuous R&D Investment

Gallagher reinvests 15% of annual revenue into R&D, keeping the platform ahead of emerging threats rather than relying on legacy hardware.

Gallagher Security (a division of Gallagher Group, distinct from the company's agricultural fencing business) makes access control, perimeter security and intrusion detection systems, with a strong presence in government, defence, airport and other high-security environments. Its Command Centre software platform integrates access control, monitoring and perimeter detection into a single management interface.

Want to know more about why we chose to work with Gallagher? Contact us.
