Aritech

Modular intrusion and access control hardware, built on the Tecom Challenger platform.

50+Years in the field
35+Years of Challenger
Door + liftTS1066 NAC8 doors or lifts eachUltraSyncEncrypted linkMonitoring and the appArea 2 armedDoor forcedLift to L4Intrusion and accessAlarms to monitoring
128 doorson one ChallengerPlus panel, with 99 areas and 1,008 inputs
250,000users held in a Network Access Controller run from software
600controllers on one WMS Pro system, with up to 300 operators
256 zoneson an Axon panel, wired, wireless or a mix of both
Two panel families

Tecom and Axon, both on UltraSync

Aritech sells two panel families in Australia. Tecom is the local range that Challenger sites have grown up on; Axon is Aritech’s newer intrusion and access panel, sold worldwide. We help you choose on site size, the hardware already on the wall and how you want to manage it.

Part armedNight areas setBanking hallArea 1 armedVault doorLockedDock rollerAlarm 02:14Comms roomSecureStaff roomArea 4 openRear PIRIsolatedLift L4Floor lockedPlant roomArea 3 armed
ChallengerPlus and Discovery

Tecom

A ChallengerPlus or Discovery panel sits at the centre, with door, lift and input modules added on its data bus as the site grows. Users, start and end dates and door groups live in the panel itself, so access rules still apply when the software link is down.

  • ChallengerPlus: up to 99 areas, 128 doors and 98 lifts
  • Discovery: the DIN-rail panel set up from a web browser
  • Network Access Controllers for four or eight doors or lifts
  • WMS Pro web software for up to 600 controllers
UltraSyncVPN tunnel to every panelServers in AustraliaRetail storeAxon panelMedical8 doorsWarehouseRecorderPortalApp
Intrusion, access and video

Axon

One panel for alarms, doors and links to video, set up from a browser on a phone, tablet or PC with guided wizards. It joins UltraSync out of the box over Ethernet or a SIM, so panels can be checked and supported remotely.

  • 16 zones on the board, up to 256 in total
  • Up to 8 doors on the panel, more with CDC4 controllers
  • Wired and wireless detectors, with plug-on expanders
  • Scheduled health checks through UltraSync
What it does

What an Aritech system does day to day

The panel is only the start. These are the parts of the range that change how a site actually runs, from the front door to the monitoring centre.

CardFobPINAccess granted08:02 Priya · L407:55 Dock door07:41 Card expired07:30 Lift L2

Doors and lifts on one controller

A Network Access Controller runs up to eight doors or lifts and up to 100 floors. It takes OSDP v2 readers and Aperio or Salto wireless locks, and when run straight from software it holds 250,000 users on board.

EntryPIR 3Cam 2Dock doorLift L1Click a door to lock or open it

Site maps

WMS Pro lets you upload a floor plan and place doors, areas and inputs on it, so guards, reception and managers can see what is happening and act on it from the drawing.

WMS Pro · alarmsControllers14Doors86Open alarms2Cardholders3,410Alarms this weekLatestDoor forced · DockArea 2 armedMains fail · Panel 3Weekly report sent

Alarm handling in the browser

Alarms from one panel or many sites arrive in one web page, ranked and colour-coded, with sound, email and full-screen alerts. Reports run on a schedule and go out by email or as PDF and CSV.

TecomPlusAlarm Area 2Dock PIR · DandenongToday 02:14View cameraIsolate inputAreasArm or disarmDoorsOpen remotelyCamerasTruVision live

Your system on your phone

The TecomPlus app reaches the panel through UltraSync. Arm and disarm areas, open doors, isolate inputs, add users and cards, and watch TruVision cameras live, with push alerts for alarms and power faults.

Yard fencePerson in yardAnimal · ignored

Cameras that ignore the wind

TruVision M series cameras tell people and vehicles apart from animals, moving branches and shadows, so far fewer false events reach the recorder and the app. Up to 8 MP, with fixed or motorised lenses.

UltraSyncChallengerPlus10 reporting paths at onceMonitoringTenant 2WMS ProTecomPlusEach path filtered by area, event and time

More than one place to report

A ChallengerPlus panel can report down ten paths at once, each filtered by area, event and time. Tenants sharing one panel can each send alarms to their own monitoring provider.

The range

What Aritech makes

Panels and controllers

  • ChallengerPlus and ChallengerLEPlus
  • Discovery DIN-rail panel
  • Axon intrusion and access panel
  • Network Access Controller, 4 or 8 doors
  • Axon CDC4 four-door and lift controller

Keypads, readers and detection

  • Arming stations and Axon touchscreen keypads
  • Card readers and credentials
  • Aritech motion sensors
  • ShatterPro glass-break detectors
  • Magnetic contacts, wired and wireless

Software and connectivity

  • WMS Pro web management
  • UltraSync cloud and installer portal
  • TecomPlus mobile app
  • Discovery 4G comms module

Video

  • TruVision M series IP cameras
  • TruVision PTZ, 360°, ANPR and thermal cameras
  • TruVision recorders and Navigator software
  • IFS network switches
How it fits together

A Teracom Aritech system, end to end

ON SITEPLATFORMPEOPLEDetectorsPIRs, reeds, glassDoors and liftsNAC and CDC4KeypadsArming stationsTruVision camerasRecorder on siteTecom or AxonPanel on siteWMS ProWeb managementUltraSyncEncrypted cloud linkSecurity deskMaps and alarmsStaffTecomPlus appMonitoring centreAlarms after hoursDetectors, doors and cameras report to the panel; WMS Pro and UltraSync put it in front of the right people

Detectors, doors, lifts and cameras connect to a Tecom or Axon panel on site. WMS Pro runs the day-to-day from a browser, UltraSync carries alarms and the app securely, and alarms can come through to our monitoring centre after hours.

Where we put it to work

  • Banks and financial institutions
  • Retail
  • Schools and universities
  • Offices and shared workspaces
  • Distribution centres
  • Councils
  • Transport
  • Apartment buildings
Teracom and Aritech

What Teracom does on an Aritech job

  1. Design

    Panel, expanders and door controllers sized from the site drawings, with areas, door groups and lift floors planned before anything is ordered.

  2. Install and commission

    Panels, readers and detectors installed and cabled, every input walk-tested, and WMS Pro set up with your floor plans and access groups.

  3. Connect to monitoring

    Alarms can come through to our monitoring centre for after-hours response, over UltraSync or a direct IP path.

  4. Look after it

    Firmware, battery tests and user changes handled on a maintenance plan, including staged upgrades from older Challenger hardware.

From Aritech: Aritech product documentation · Tecom range and compatibility · Aritech product warranty

Why Teracom works with Aritech

Modular security engineered to grow with your site.

One Platform, Every Layer

Tecom/Forcefield unifies intrusion, access control and video into a single integrated system, so operators manage doors, alarms, cameras, recorders and intercoms from one screen instead of juggling separate consoles.

Add-As-You-Grow Design

Challenger's modular architecture lets you add door or lift controllers, I/O expanders, memory expanders and LAN devices to the same panel, scaling from a single site to an enterprise footprint without ripping anything out.

Proven Since 1989

The Challenger control panel has protected Australian and New Zealand sites since 1989, and the current ChallengerPlus and Discovery ranges are built directly on that same field-tested architecture.

Upgrade, Don't Replace

ChallengerPlus and Discovery are designed so existing Tecom customers can move up in hardware and capability while protecting their original investment, including the ability to revert to Challenger10 firmware if needed.

Designed and Made in Australia

Discovery hardware is designed, developed and manufactured in Australia, keeping engineering and production close to the market it serves.

Aritech is the brand under which Kidde Global Solutions now sells the Tecom Challenger security platform -- a modular intrusion and access control system Teracom has worked with for years under its earlier Tecom Challenger name. At the heart of a Challenger system is the Challenger panel itself: a modular, "add as you go" design that scales by adding intelligent door and lift controllers, input/output expanders, memory expanders and LAN devices as a site grows, with multiple panels able to link together under one piece of management software. That means a solution can start at a single office and expand to a multi-site environment without being re-engineered from scratch, combining intrusion detection, access control and video surveillance integration into one interface.

The current hardware range covers a few tiers. The Network Access Controller manages door and access requirements and supports intrusion applications, and can connect directly to management software or to a ChallengerPlus panel for combined access and intrusion capability. ChallengerPlus is the higher-capacity option, built for commercial and corporate environments such as banks, retail and education, with thousands of programmable options and compatibility with UltraSync and the TecomPlus mobile app. ChallengerLEPlus is the compact, cost-effective version for locations where panel space is limited, offering most of the same advanced features along with an encrypted UltraSync connection to a monitoring station and mobile app control.

On the software side, installers can program a Challenger system on site or remotely over a modem or IP connection, and end users manage doors, alarms and video surveillance through Security Commander, including an interactive map of the building for quick operator control. The TecomPlus mobile app extends day-to-day control to a phone -- arming and disarming areas, opening doors, isolating inputs and checking input/relay status -- and the wider software suite provides integrated management across multiple systems from one place.
